M57 - The Ring Nebula
| Object | M57, The Ring Nebula, in Lyra | |
| Telescope (Photo) | TeleVue 85mm OTA @ f/5.6 (480mm focal length) on ZWO AM5N mount | |
| Telescope (Guiding) | William Optics UniGuide 32mm f/3.75 guide scope on ZWO AM5N mount | |
| Camera (Photo) | Touptek ATR585M monochrome CMOS Camera with Touptek 7 position 1.25" filter wheel, controlled by N.I.N.A. | |
| Camera (Guiding) | ZWO ASI220MM Mini w/PHD2 Guiding | |
| Exposure Detail |
Combination of 40 images, each 180 seconds: 20 Ha 20 OIII Total 2 hours data capture, using Touptek narrowband filters. Calibrated with dark, flat-dark, and flat frames; image processing w/PixInsight 1.9.4 |
|
| Location | Quilted Starfields Observatory (N29.406, W82.859) | |
| Date | 06/11/2026 |
