NGC7830 - The Wizard Nebula



The Wizard Nebula in Narrowband























  Object NGC7830 - The Wizard Nebula, in Cepheus (uncropped)
  Telescope (Photo) TeleVue 85mm OTA @ f/5.6 on Losmandy G-11 Mount
  Telescope (Guiding) Off-axis using ZWO OAG-Large with TeleVue 85mm OTA @ f/5.6 on Losmandy G-11 mount t
  Camera (Photo) ZWO ASI6200MM Pro full-frame monochrome CMOS Camera with ZWO 7 position 2" filter wheel, controlled by Sequence Generator Pro
  Camera (Guiding) ZWO ASI174MM Mini w/PHD2 Guiding
  Exposure Detail Combination of 120 images at 600 seconds each:
   40 SII
   40 Ha
   40 OIII
Combination of 60 images at 60 seconds each:
   20 Red (stars)
   20 Green (stars)
   20 Blue (stars
Total 21 hours data capture, using ZWO 2" narrowband and RGB filters.  Calibrated with bias, dark, flat-dark, and flat frames; image processing w/PixInsight 1.8.9
Location Quilted Starfields Observatory, Chiefland, FL  (N29.406, W82.859)
  Date 09/20/2024 - 09/23/2024
